MF1S5030XDA8/V1J
RFID Module Read-Write, 13.56MHz, 1KB, 30mA Consumption, UART Interface, MIFARE Classic Series
Pilt on illustreeriv. Lugege toote kirjeldust.
TootjaNXP
Tootja toote nrMF1S5030XDA8/V1J
Tellimiskood2820251
TootevalikMIFARE Classic Series
Tehniliste andmete leht
Saadaval tellimiseks
Tootja standardne tarneaeg: 16 nädal(at)
Teavitage mind, kui toode on uuesti laos
| Kogus | |
|---|---|
| 30000+ | 0,544 € |
Hind:Each (Supplied on Cut Tape)
Minimaalne: 30000
Mitmekordne: 30000
16 320,00 € (KM-ta)
Lisage tootenr/ /tootemärkus
Lisatud teie tellimuse kinnitusele, arvele ja väljastusteatele ainult sellel tellimusel.
See arv lisatakse tellimuse kinnitusele, arvele, väljastusteatele, veebipõhisele kinnitusmeilile ja tootesildile.
Tooteteave
TootjaNXP
Tootja toote nrMF1S5030XDA8/V1J
Tellimiskood2820251
TootevalikMIFARE Classic Series
Tehniliste andmete leht
Frequency13.56MHz
Memory Size1KB
Current Consumption30mA
Supply Voltage Min-
Supply Voltage Max-
Module InterfaceUART
Product RangeMIFARE Classic Series
SVHCNo SVHC (27-Jun-2024)
Toote ülevaade
MF1S5030XDA8/V1J is a MIFARE Classic EV1 1K - mainstream contactless smart card IC module for fast and easy solution development. Typical applications include public transportation, electronic toll collection, school and campus cards, internet cafés, access management, car parking, employee cards and loyalty.
- Contactless transmission of data and energy supply
- Operating frequency of 13.56MHz
- Data integrity of 16bit CRC, parity, bit coding, bit counting
- Typical ticketing transaction time of <lt/> 100ms (including backup management)
- Random ID support (7 Byte UID version)
- Operating distance up to 100mmdepending on antenna geometry and reader configuration
- Data transfer of 106Kbit/s and anticollision
- 7 Byte UID or 4byte NUID and 1KB, organized in 16 sectors of 4 blocks (1 block consists of 16 byte)
- Data retention time of 10 years and write endurance 200000 cycles
- User definable access conditions for each memory block
Hoiatused
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Tehnilised andmed
Frequency
13.56MHz
Current Consumption
30mA
Supply Voltage Max
-
Product Range
MIFARE Classic Series
Memory Size
1KB
Supply Voltage Min
-
Module Interface
UART
SVHC
No SVHC (27-Jun-2024)
Tehnilised dokumendid (2)
Seadusandlus ja keskkonnateave
Päritoluriik:
Riik, kus toimus viimane oluline tootmisprotsessPäritoluriik:China
Riik, kus toimus viimane oluline tootmisprotsess
Riik, kus toimus viimane oluline tootmisprotsessPäritoluriik:China
Riik, kus toimus viimane oluline tootmisprotsess
Tariifi nr:85423990
US ECCN:5A992.c
EU ECCN:NLR
RoHS-ile vastav:Jah
RoHS
Vastab RoHS-i ftalaatide nõuetele:Jah
RoHS
Väga ohtlik aine:No SVHC (27-Jun-2024)
Laadige alla vastavussertifikaat
Toote vastavussertifikaat
Kaal (kg):.0003
Toote jälitatavus
