1296.2022
Light Pipe, Miniature Double Line, 11.85 mm, 4 Pipes, Circular, PC Board, Transparent
Pilt on illustreeriv. Lugege toote kirjeldust.
Ei ladustata enam
Tooteteave
TootjaMENTOR
Tootja toote nr1296.2022
Tellimiskood2300645
Tehniliste andmete leht
Length11.85mm
No. of Light Pipes4Pipes
Light Pipe ShapeCircular
Light Pipe MountingPC Board
Light Pipe ColourTransparent
Product Range-
SVHCNo SVHC (15-Jan-2019)
Toote ülevaade
The 1296.2022 is a Ø2mm lying miniature multiple Light Guide recommended for use with R2 to R3 and R11 to R13 LEDs. It is designed for the use of type 0603 CHIPLEDs or smaller types and has a grid dimension of 2.54mm. The system features a light diffusing cover enabling the use of different colours. The double light guide elements arranged one above the other contain up to a maximum of 4 radiating surfaces and are mounted on the printed board with a press-in lug.
- UL94 Flammability rating
- -40 to 85°C Ambient temperature range
- <8kV ESD protection
Rakendused
Industrial, Lighting
Tehnilised andmed
Length
11.85mm
Light Pipe Shape
Circular
Light Pipe Colour
Transparent
SVHC
No SVHC (15-Jan-2019)
No. of Light Pipes
4Pipes
Light Pipe Mounting
PC Board
Product Range
-
Tehnilised dokumendid (1)
Seotud tooted
Leiti 1 toodet
Seadusandlus ja keskkonnateave
Päritoluriik:
Riik, kus toimus viimane oluline tootmisprotsessPäritoluriik:Germany
Riik, kus toimus viimane oluline tootmisprotsess
Riik, kus toimus viimane oluline tootmisprotsessPäritoluriik:Germany
Riik, kus toimus viimane oluline tootmisprotsess
Tariifi nr:90019000
RoHS-ile vastav:Jah
RoHS
Vastab RoHS-i ftalaatide nõuetele:Vajab kinnitamist
Väga ohtlik aine:No SVHC (15-Jan-2019)
Laadige alla vastavussertifikaat
Toote vastavussertifikaat
Kaal (kg):.022
