VM-2HXL

Distribution amplifier for HDMI signals. Reclocks and equalizes the signal and distributes it to a number of identical outputs.

• Max. Data Rate: 1.65Gbps
• HDCP Compliant
• Enhanced EDID (Extended Display Identification Data)
• The unit can store and recall a default EDID setting in non-volatile memory from one of the outputs
• Allows for convenient and reliable connection to the source
• Active Input & Output LED Indicators
• Inputs: 1x HDMI connector
• Outputs: 2x HDMI connectors
• Supplied with power supply (12Vdc, 170mA) and mounting bracket
• Dimensions (WxHxD): 120 x 25 x 75mm
• Weight: 300g
• UK mains plug (type G), as used in the UK, IRL, Cyprus, Saudi Arabia, Malta and many others.
