Fixed Network Resistors | Farnell Eesti

Leidke poest Farnell Eesti suur valik tooteid Fixed Network Resistors. Meil on suur valik Fixed Network Resistors, sealhulgas uusi ja populaarsemaid tooteid maailma tipptootjatelt, sealhulgas: Panasonic, Bourns, Multicomp Pro, Yageo & Bourns / Partner Stock

Tootja tootenumber	Tellimiskood	Tootja / Kirjeldus	Hind tootele	Hind (KM-ta)	Resistance	Network Circuit Type	No. of Resistors	Resistor Case / Package	Resistor Terminals	Resistance Tolerance	Voltage Rating	Power Rating per Resistor	Temperature Coefficient	Resistor Type	Resistor Technology	Resistor Mounting	Terminal Pitch	Power Rating	Product Length	Product Width	Product Height	Product Range	Operating Temperature Min	Operating Temperature Max	Qualification

4610X-104-221/331L	2908124 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 330 ohm Dual Terminator 16 Resistors SIP PC Pin ± 2%	Each	1+0,550 € 50+0,270 € 100+0,213 € 250+0,179 € 500+0,167 € Veel hinnateavet ...	330ohm	Dual Terminator	16Resistors	SIP	PC Pin	± 2%	100V	200mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	1.25W	25.35mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
4816P-T01-223LF	2908133 Data Sheet RoHS	BOURNS Fixed Network Resistor 22 kohm Isolated 8 Resistors SOIC Gull Wing ± 2%	Each	1+1,660 € 3+1,160 € 5+1,030 € 10+0,893 € 20+0,830 € Veel hinnateavet ...	22kohm	Isolated	8Resistors	SOIC	Gull Wing	± 2%	50V	160mW	± 100ppm/°C	Network	Thick Film	Surface Mount Device	1.27mm	1.28W	11.18mm	5.59mm	2.16mm	4800P Series	-55°C	125°C	AEC-Q200
MP005627	3550052 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 120 kohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0319 € 100+0,0199 € 500+0,0165 € 1000+0,0141 € 2500+0,0129 €	120kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	MP 4D	-55°C	155°C	-
CAY16-181J4LF	2008292 Data Sheet RoHS	BOURNS Fixed Network Resistor 180 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0343 € 100+0,0237 € 500+0,0218 € 1000+0,0197 € 2500+0,018 € Veel hinnateavet ...	180ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	62mW	-	Array	-	Surface Mount Device	0.8mm	250mW	3.2mm	1.6mm	0.5mm	CAY16 Series	-55°C	125°C	-
CAT16-203J4LF	2908147 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 20 kohm Isolated 4 Resistors 1206 [3216 Metric] Concave ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0129 € 100+0,0102 € 500+0,0073 € 1000+0,0058 € 2500+0,0055 € Veel hinnateavet ...	20kohm	Isolated	4Resistors	1206 [3216 Metric]	Concave	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	250mW	3.2mm	1.6mm	0.5mm	CAT16 Series	-55°C	125°C	-
4816P-T02-473LF	2908137 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 47 kohm Bussed 15 Resistors SOIC Gull Wing ± 2%	Each	1+1,470 € 3+1,150 € 5+1,020 € 10+0,893 € 20+0,823 € Veel hinnateavet ...	47kohm	Bussed	15Resistors	SOIC	Gull Wing	± 2%	50V	80mW	± 100ppm/°C	Network	Thick Film	Surface Mount Device	1.27mm	1.28W	11.18mm	5.59mm	2.16mm	4800P Series	-55°C	125°C	AEC-Q200
MP005678	3550109 Data Sheet RoHS	MULTICOMP PRO Fixed Network Resistor 680 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0348 € 100+0,0217 € 500+0,0179 € 1000+0,0141 € 2500+0,0129 €	680ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	MP 4D	-55°C	155°C	-
MP005657	3550086 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 33 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0419 € 100+0,0263 € 500+0,0216 € 1000+0,0171 € 2500+0,0155 €	33ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	MP 4D	-55°C	155°C	-
MP005607	3550030 Data Sheet RoHS	MULTICOMP PRO Fixed Network Resistor 5.1 kohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0282 € 100+0,0177 € 500+0,0145 € 2500+0,0115 € 5000+0,0105 €	5.1kohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	-	2mm	1mm	0.45mm	MP 4D	-55°C	155°C	-
CAY16A-102J4LF	3769713 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 1 kohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0784 € 100+0,0484 € 500+0,0429 € 1000+0,0353 € 2500+0,0318 € Veel hinnateavet ...	1kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	CAY16A-LF Series	-55°C	125°C	AEC-Q200
MP005594	3550016 Data Sheet RoHS	MULTICOMP PRO Fixed Network Resistor 2 kohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0282 € 100+0,0177 € 500+0,0145 € 2500+0,0115 € 5000+0,0105 €	2kohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	-	2mm	1mm	0.45mm	MP 4D	-55°C	155°C	-
MCRE000216	1711700 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 4.7 kohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 1%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0239 € 100+0,0157 € 500+0,0119 € 2500+0,0096 € 5000+0,0094 €	4.7kohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 1%	25V	-	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	62.5mW	2mm	1mm	0.45mm	MP CN Series	-55°C	125°C	-
CAT16-33R0F4LF	2908154 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 33 ohm Isolated 4 Resistors 1206 [3216 Metric] Concave ± 1%	Each	10+0,0669 € 100+0,0413 € 500+0,0366 € 1000+0,0302 € 2500+0,0271 € Veel hinnateavet ...	33ohm	Isolated	4Resistors	1206 [3216 Metric]	Concave	± 1%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	250mW	3.2mm	1.6mm	0.5mm	CAT16 Series	-55°C	125°C	-
4816P-T02-222LF	2908136 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 2.2 kohm Bussed 15 Resistors SOIC Gull Wing ± 2%	Each	1+1,730 € 3+1,700 € 5+1,670 € 10+1,050 € 20+0,933 € Veel hinnateavet ...	2.2kohm	Bussed	15Resistors	SOIC	Gull Wing	± 2%	50V	80mW	± 100ppm/°C	Network	Thick Film	Surface Mount Device	1.27mm	1.28W	11.18mm	5.59mm	2.16mm	4800P Series	-55°C	125°C	AEC-Q200
MP000968	3228714 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 470 kohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 1%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0388 € 100+0,0243 € 500+0,020 € 2500+0,0158 € 5000+0,0144 €	470kohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 1%	25V	62.5mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	-	2mm	1mm	0.45mm	MP CN Series	-55°C	155°C	-
MP005660	3550089 Data Sheet RoHS	MULTICOMP PRO Fixed Network Resistor 39 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,033 € 100+0,0207 € 500+0,017 € 1000+0,0134 € 2500+0,0123 €	39ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	MP 4D	-55°C	155°C	-
MP005654	3550082 Data Sheet RoHS	MULTICOMP PRO Fixed Network Resistor 300 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0326 € 100+0,0204 € 500+0,0168 € 1000+0,0132 € 2500+0,0121 €	300ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	MP 4D	-55°C	155°C	-
MP005595	3550017 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 3.3 kohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0306 € 100+0,0192 € 500+0,0157 € 2500+0,0125 € 5000+0,0114 €	3.3kohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	-	2mm	1mm	0.45mm	MP 4D	-55°C	155°C	-
4116R-1-680LF	9355995 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 68 ohm Isolated 8 Resistors DIP PC Pin ± 2%	Each	1+2,590 € 3+1,960 € 5+1,780 € 10+1,600 € 20+1,550 € Veel hinnateavet ...	68ohm	Isolated	8Resistors	DIP	PC Pin	± 2%	100V	250mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	2.25W	21.97mm	6.71mm	4.57mm	4100R Series	-55°C	125°C	-
MP000956	3228700 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 56 ohm Isolated 2 Resistors 0302 [0806 Metric] Flat ± 1%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0735 € 100+0,0461 € 500+0,0378 € 2500+0,0326 € 5000+0,0297 €	56ohm	Isolated	2Resistors	0302 [0806 Metric]	Flat	± 1%	12.5V	31.25mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	-	0.8mm	0.6mm	0.35mm	MP CN Series	-55°C	125°C	-
CAY16A-471J4LF	3769757 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 470 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0628 € 100+0,0413 € 500+0,0329 € 1000+0,030 € 2500+0,0284 € Veel hinnateavet ...	470kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	CAY16A-LF Series	-55°C	125°C	AEC-Q200
CAY16A-101J4LF	3769778 Data Sheet RoHS Date/Lot Code	BOURNS Fixed Network Resistor 100 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0784 € 100+0,0484 € 500+0,0429 € 1000+0,0353 € 2500+0,0318 €	100ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	CAY16A-LF Series	-55°C	125°C	AEC-Q200
4114R-1-470LF	9355715 Data Sheet RoHS	BOURNS Fixed Network Resistor 47 ohm Isolated 7 Resistors DIP PC Pin ± 1ohm	Each	1+1,280 € 3+1,090 € 5+0,944 € 10+0,868 € 20+0,770 € Veel hinnateavet ...	47kohm	Isolated	7Resistors	DIP	PC Pin	± 1ohm	100V	250mW	± 250ppm/°C	Network	Thick Film	Through Hole	2.54mm	2W	19.43mm	6.71mm	4.57mm	4100R Series	-55°C	125°C	-
MP000975	3228722 Data Sheet RoHS	MULTICOMP PRO Fixed Network Resistor 100 ohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0286 € 100+0,0179 € 500+0,0147 € 2500+0,0116 € 5000+0,0107 €	100ohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 5%	25V	62.5mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	-	2mm	1mm	0.45mm	MP CN Series	-55°C	155°C	-
MP000961	3228705 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 10 kohm Isolated 4 Resistors 0502 [1406 Metric] Flat ± 5%	Each (Supplied on Cut Tape) Lõigatud linditükk	10+0,0761 € 100+0,0477 € 500+0,0391 € 2500+0,0309 € 5000+0,0283 €	10kohm	Isolated	4Resistors	0502 [1406 Metric]	Flat	± 5%	12.5V	31.25mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.4mm	-	1.4mm	0.6mm	0.35mm	MP CN Series	-55°C	125°C	-
