M18TIP8Q
Sensor, Temperature, -20 to 300 °C, PNP, 4 to 20 mA, 8:1 View, 30 VDC, T-GAGE M18T Series
Pilt on illustreeriv. Lugege toote kirjeldust.
TootjaBANNER ENGINEERING
Tootja toote nrM18TIP8Q
Tellimiskood4297181
TootevalikM18T Series
Tehniliste andmete leht
Saadaval tellimiseks
Tootja standardne tarneaeg: 6 nädal(at)
Teavitage mind, kui toode on uuesti laos
| Kogus | |
|---|---|
| 1+ | 542,770 € |
| 5+ | 531,910 € |
| 10+ | 521,060 € |
| 25+ | 510,200 € |
| 50+ | 499,350 € |
Hind:Each
Minimaalne: 1
Mitmekordne: 1
542,77 € (KM-ta)
Lisage tootenr/ /tootemärkus
Lisatud teie tellimuse kinnitusele, arvele ja väljastusteatele ainult sellel tellimusel.
See arv lisatakse tellimuse kinnitusele, arvele, väljastusteatele, veebipõhisele kinnitusmeilile ja tootesildile.
Tooteteave
TootjaBANNER ENGINEERING
Tootja toote nrM18TIP8Q
Tellimiskood4297181
TootevalikM18T Series
Tehniliste andmete leht
Supply Voltage30VDC
Sensing Temperature Min-20°C
Sensing Temperature Max300°C
Response Time75ms
Operating Temperature Min-20°C
Operating Temperature Max70°C
Analogue Outputs4mA to 20mA
Digital OutputsPNP
Mounting Thread-
Field of View (NETD)8:1
EmissivityFixed 1
Product RangeM18T Series
SVHCNo SVHC (15-Jan-2018)
Toote ülevaade
- T-GAGE™ M18T series non contact, infrared temperature sensor
- Fast 75ms response time, chemical resistant, health/marginal signal output
- Easy-to-use TEACH configuration without potentiometer adjustments
- Small, self-contained package; no auxiliary controller needed
- Rugged encapsulated design for harsh environments
- Product motion not required for sensing, alarm output for signal maximum
- Configuration for either positive or negative analogue slope based on teach order
- 5-pin M12 integral QD cable, 8:1 D:S ratio, integrated lens sensing face
- 12VDC to 30VDC supply voltage range, 4 to 20mA analogue, plus PNP Alarm output
- Operating temperature range from -20 to 70°C
Hoiatused
Do not use this device for personnel protection. Using this device for personnel protection could result in serious injury or death.
Tehnilised andmed
Supply Voltage
30VDC
Sensing Temperature Max
300°C
Operating Temperature Min
-20°C
Analogue Outputs
4mA to 20mA
Mounting Thread
-
Emissivity
Fixed 1
SVHC
No SVHC (15-Jan-2018)
Sensing Temperature Min
-20°C
Response Time
75ms
Operating Temperature Max
70°C
Digital Outputs
PNP
Field of View (NETD)
8:1
Product Range
M18T Series
Tehnilised dokumendid (2)
Seadusandlus ja keskkonnateave
Päritoluriik:
Riik, kus toimus viimane oluline tootmisprotsessPäritoluriik:United States
Riik, kus toimus viimane oluline tootmisprotsess
Riik, kus toimus viimane oluline tootmisprotsessPäritoluriik:United States
Riik, kus toimus viimane oluline tootmisprotsess
Tariifi nr:85176200
US ECCN:EAR99
EU ECCN:NLR
RoHS-ile vastav:Jah
RoHS
Vastab RoHS-i ftalaatide nõuetele:Jah
RoHS
Väga ohtlik aine:No SVHC (15-Jan-2018)
Laadige alla vastavussertifikaat
Toote vastavussertifikaat
Kaal (kg):.090718
